Letradora Manual de Lujo para Doblar Letras de Acrilico, Tipo A+U
  • Letradora Manual de Lujo para Doblar Letras de Acrilico, Tipo A+U
  • Letradora Manual de Lujo para Doblar Letras de Acrilico, Tipo A+U
  • Letradora Manual de Lujo para Doblar Letras de Acrilico, Tipo A+U
  • Letradora Manual de Lujo para Doblar Letras de Acrilico, Tipo A+U

Ver imagen más grande y otras vistas (con zoom)

Letradora Manual de Lujo para Doblar Letras de Acrilico, Tipo A+U

Precio CON IVA,Pero no Incluye Pago Paypal.

   |   49 Transacciones

Codigo del articulo:SIT-CS-HD-BC06

  • Precio Unitario : Mex.$ 483 - 531/set   (Aviso de Descuento) (en existencia)

    Precio de Mayoreo :
    • Cantidad (sets) Descuento Amount/set
      1. 1 - 2 0% Mex.$531
      2. 3 - 4 3% Mex.$515
      3. 5 - 6 6% Mex.$499
      4. 7 - 9% Mex.$483
    • ¿Necesitas más cantidades, por favor haga clic en Pedido al mayoreo
  • Cantidad: set(s) Costo Total : MXN Mex.$531
  • Peso de Envio: 2.2lb (1kg) freightFlete

  • Submit your order online to get membership points, a proforma invoice will be sent to you after you submit the order.
    Add to  Cart
Buyer Protection



Letradora Manual de Lujo, Tipo A+U, Acrilico
Descripcion:
Material: Acrilico, Plastico, PVC, Plexiglas
Letradora Manual de Lujo, Tipo U, Acrilico, es ideal para fabricar letras o señales de acrilico.
Apto para doblar acrilico de 1.5mm-4mm (0.06" x 0.16") grueso


• Adoptando elementos de calentado PTC ;
• Placa conductora de calor de aleacion termal se calienta uniformemente;
• Adopta plasticol de alta calidad resistentes al calor, no se pega el acrilico;
• Facil de operar y durable.

• Los elementos de calentamiento PTC tienen caracteristicas como, rapido calentamiento, durable, control automatico de temperatura.
• Placa conductora de aleacion de aluminio se ajusta al angulo entre la placa y el acrilico.
• Dobla angulos rectos.
• Dobla esquinas redondas.
• Facil de operar, ahorra tiempo.
• Garantia: 2 años.


Voltaje: AC 100-240V
Potencia: Arc bending 60W±10%
Temperatura: 200°C±5%
Altura de materialt: 0 - 100mm (3.9")
Grosor de material: 1.5mm - 4mm
Tiempo de calentado (2.5mm thickness, 20°C): About 9 seconds
Tamaño: 100mm x 50mm x 2mm (3.9" x 2" x 0.08")

Cable rotativo de 360 grados: Debido al uso frecuente de la herramienta, el cable de corriente puede sufrir daños. Pero nuestro modelo evita el daño al cable gracias a su diseño rotativo de 360 grados.











Remarks:
• You’d better use the bender with proper strength; otherwise it will cause heat loss and heat uneven.
• If the arc length is greater than heating plate breadth, you can use the arc bender to heat 1-3 times continuously and arrange in a row. The arc length be bent is within 150mm.
• With short preheat time; restart the bender won't waste too much time. If you do not use it more than 5 minutes, please shut off the power switch to save electricity.
• Please do not put the heating plate onto the power cable.
• Kindly remind you that heating transparent acrylic could leave tiny marks on the material, which is not clear on the acrylic of other colors. Please notice it when you place an order.
• 1pc PTFE Coated Fiberglass Adhesive Tape will be gift for you when you buy A type angle bending tools.

How to use the High Temperature PTFE Coated Fiberglass Adhesive Tape?
Place cut the adhesive tape into 3mm width, and then stick them on both sides of angle bender respectively. The PTFE Coated Fiberglass adhesive tape can be used many times.
You can use the PTFE Coated Fiberglass Adhesive Tape when you want heat PVC board.

Comparison for Our Original Acrylic Bender and Copycat Acrylic Bender
For now there are many copycat acrylic bender, Acrylic bending machine, handheld acrylic bending tools in the market with inferior quality and awful performance.
It will highly effect work efficiency in 3D letter channel making process.
We list the comparison between our original acrylic bender and copycats acrylic bender as below; it is for clients better knowing how to choose acrylic bender before purchase.
We bought copycats products below and disassemble them to list their parts and our acrylic bender inside parts for clients better knowing about their quality.
Heating plate of our Acrylic Bender Heating plate of COPYCAT Acrylic Bender
Temperature Control PCB part of our Acrylic Bender Temperature Control PCB part of COPYCAT
Acrylic Bender
Power Switch part of our Acrylic Bender Power Switch part of COPYCAT Acrylic Bender
Power Plug of our Acrylic Bender Power Plug of COPYCAT Acrylic Bender



PERFORMANCE COMPARISON
Our Acrylic Bender COPYCAT Acrylic Bender

About heating insulation film, the reason our acrylic bender do not put heat insulation film is the operator do not need to use finger to clamp this area to bend acrylic sheet. If you choose our original acrylic bender, you just need to handheld to operate as bellow.
As the copycat cannot hold the acrylic sheet seamlessly so that will need your finger to help to bend it like below
picture, so they have to put insulation film or their acrylic bender cannot hold and bend acrylic bender fully.
Our Acrylic Bender COPYCAT Acrylic Bender
About Vertical guide in copycat products, as we design acrylic bender its head are all flat, so it will have an vertical angle against desk when operator use it, so this vertical guide is totally useless. Our Acrylic bender head are all designed to be flat, that will have vertical angle when operator use it against desk

Connect the power cable, after about 60 seconds heating time, you can use the bender.
Using the angle or arc bender vertically clamp the acrylic plate, soften the acrylic plate several seconds, and then remove the bender, make angle and arc you want, fix it with glue.
Sharp Corner Bending Machine Tool (Acrylic Angle Bending Machine Tool)

Round Corner Bending Machine Tool (Acrylic Arc Bending Machine Tool)



Processing Material: Acrylic, Plastic, PVC, Plexiglass
This type acrylic bender is ideal for LED Acrylic Lighting Channel Letters, acrylic sign letters making.
